Digital Amplifier Audio Board TDA7498 Power Audio Amp 2.0 Class D Stereo HIFI DC12-36V 2*100W

Details Parameter Item Name TDA7498 amplifierItem model WM 033Supply Voltage DC 12 36VOutput Power Max100WX2Sound Channel 2 ChannelsOutput Impedance 4 8 ohmFrequency 20Hz 20KHzDimension 83 64 26mmWeight 105g Features 100 W 100 W output power atTHD 10 with RL 6 Q and Vcc 36 V80 W 80 W output power atTHD 10 with RL 8 and Vcc 34 VWide range single supply operation 14 39 V High efficiency n 90 Four selectable fixed gain settings of nominally 25 6 dBt 31 6 dB 35 1 dB and 37 6 dBDifferential inputs minimize common mode noiseStandby and mute featuresShort circuit protectionThermal overload protectionExternally synchronizable Description The TDA7498 is a dual BTL class D audio amplifier with single power supply designed for home systems and active speaker applications It comes in a 36 pin PowerSSO package with exposed pad up EPU to facilitate mounting a separate heatsink Package includes 1 x TDA7498 amplifier module
