Development Board ESP32-IO Development Expansion Board Module Programming

Introduction: It consists of a keyes ESP32-IO expansion board and a keyes ESP32 Core board Development board composition when using only need to input DC 7-12V voltage on the black DC head then It can supply power to the keyes ESP32 Core board. And the expansion board also comes with 1 dial code Switch used to control the power switch. Developers can connect peripherals according to their needs. Make When using the development board for development and debugging the standard headers on both sides can make your operation easier Clean and convenient. ESP-WROOM-32 module is the industry’s leading integrated WiH + Bluetooth solution Less than 10 external components it integrates antenna switch radio frequency balun power amplifier Converters low-noise amplifiers filters and power management modules. At the same time it also integrates TSMC low-power 40nm technology power performance and radio frequency performance safe and reliable easy to expand Expand to various applications. Feature: Microcontroller: ESP-WROOM-32 module USB to serial port chip: CP2102-GMR Power supply voltage: DC 7-12V Working current: 60mA Maximum power: 0.3W Working temperature: -25°C to +65°C WiFi mode: Station/SoftAP/SoftAP+Station/P2P WiFi protocol: 802.11 b/g/n/e/i (802.11n speed up to 150Mbps） WiFi frequency range: 2.4 GHz ~ 2.5 GHz Bluetooth protocol: comply with Bluetooth V4.2BR/EDR and BLE standards Size: 67*50*19mm Weight: 32.8g Package includes: 1 x Expansion board
