Deauther MiNi WiFi ESP8266 Development Board with OLED

What is itThis tiny ESP8266 development board is a small version of our WiFideauther projects. It comes installed with the latest ESP8266 Deauther software.With this software, you can perform different attacks to test WiFi networks.Please note that the ESP8266 does only support 2.4GHz. For more details on the software, visithere.You can also use it to develop your own software. It is simple to use, just like any other ESP8266 development board.GPIOs and hardware info:Display: SH1106 1.3" OLEDDisplay SDA: GPIO 5 (D1)Display SCL/SCK: GPIO 4 (D2)WS2812b LED: GPIO 15 (D8)Button Up: GPIO 12Button Down: GPIO 13Button Select: GPIO 14High Light LED: GPIO16All ESP8266 pins break ou.What makes it specialOnly ~80mA power usageLM39100 Low Voltage Low-Dropout RegulatorTP4056+PL5353A battery protection solutionIncluded 2dB antennaAll GPIO breakouts and 3.3 and 5V output2 LEDs to indicate battery charging status (Red:Charging,Green:Full)Protection: short, over charging, over discharging, temperatureUsageYou can use it with thedisplay and buttons:You can also connect to "pwned" with the password "deauther" anduse the web interface:If you lost the password you canresetit:WiKi:https://github.com/spacehuhn/esp8266_deauther/wikiBlog:https://dstike.com/blogs/news/about-those-copyca-products-of-minePackage Included:1 xDSTIKE Deauther MiNi WiFi ESP8266 Delopment Board with OLED
