DY29 Automotive OBD Interface Diagnostic Protocol Detector Detects Diagnostic Signal Detector

1111MicrosoftInternetExplorer402DocumentNotSpecified7 8 磅Normal0Product Description DY29 This is an automotive tool for the OBDII diagnostic link connector which offers easy access to the OBDII connector for monitoring signals of protocol power and grounds conveniently and safely It can be also connected to multi meter or oscilloscope for further testing once unconfirmed signals detected Selling point Probing at the OBDII connector is no longer required Easily access each of the 16 pins while scan tool communicating with vehicle LEDs to quickly indicate power or ground problems of OBDII connector Mimics the OBDII connector layout for quick reference Quick safe and convenient access to chassis ground and power by this monitor Uses safety banana sockets that accept all types of 4mm banana plugs including those with safety sheaths Parameters LED INDICATIONSYellow LED Pin 2 6 7 10 14 15 Light up to show communication with scan tool and protocolidentification Green LED Pin 4 5 Light up to show ground is good Red LED Pin16 Light up to show there is power Package contents Manual 1Host 1
