DSO150 Digital Electronic Oscilloscope Set With Housing Case Probe Fully DIY Assemble Tools Kit

DSO150 Digital Electronic Oscilloscope Set With Housing Case Probe Fully DIY Assemble Tools Kit
oscilloscope
sku: 1392828
ACCORDING TO OUR RECORDS THIS PRODUCT IS NOT AVAILABLE NOW
$29.81
Shipping from: China
   Description
Specification: Color: Colorful Material: Plastic + Electronic component Highest real-time sampling rate: 1Msps Accuracy: 12Bit Sample buffer depth: 1024 bytes Analog bandwidth: 0 - 200KHz Vertical sensitivity: 5mV/Div 20V/Div (progressive by 1-2-5) Input impedance: 1M Maximum input voltage: 50Vpp (1:1 probe) 400Vpp (10:1 probe) The coupling method includes: DC/AC/GND Horizontal time base range: 10s/Div 50s/Div (progressive by 1-2-5) Size: (L)X(W)X(H) 103X75X23mm /4.06''X2.95''0.91"(appr.) Function: 1. Can be triggered by a rise or drop edge. 2. Comes with 1KHz / 3.3V square wave test signal source. 3. Vertical displacement is adjustable and with instructions. 4. Observe the waveform before the trigger (negative delay). 5. The trigger level position is adjustable and with instructions. 6. The waveform display can be frozen at any time (HOLD function). 7. Save/tune out the waveform, the shutdown waveform does not disappear. 8. Automatic, regular and single trigger mode for easy capture of instantaneous waveforms. 9. With waveform parameter digital display, the parameters that can be displayed are: frequency, period, pulse width, duty ratio, maximum value, minimum value, average value, peak value, effective value. Features: Fully assembled, be patient. Higher sensitivity, good performance. 2.4-inch color TFT LCD with 320 x 240 resolution. Rotary coding switch is adopted to make parameter adjustment more convenient. An oscilloscope has a complete enclosure with separate panels and upper and lower baffles for user modification. ATTENTION: The oscilloscope uses a 9V DC power supply (the power supply voltage must not exceed 10V. Otherwise it may burn out the machine). The kit itself does not contain power, users need to prepare their own power supply, the power supply current should be able to provide more than 200mA Package Included: 1 Set Digital Oscilloscope DIY Kit
