DSLogic Logic Analyzer 16 Channels 400M Sampling USB-based Debugging Logic Analyzer

Description DSLogic is a USB based logic analyzer Based on Xilinx Spartan 6 FPGA SDRAM product architecture can provide up to 400 MHZ real time sampling the status of 50 MHZ sampling sampling depth of 16 M 16 channel Technical indicators as shown below Maximum sampling rate 4 channels 400 MHZ8 channels 200 MHZ16 channels 100 MHZThe onboard storage depth Total 256 K 16 m samples per channel Continuous adjustable threshold voltage range 0 5 V to 5 VThe input voltage range 30 v to 30 vInput impedance 250 kohmInput channel bandwidth 30 MHZThe largest state sampling clock 30 MHZDifferent from other entry level DSLogic logic analyzer features basically has the following several aspects Low 256 mbit on board memory ensure real time storage of up to 1 6 Gbps sampling data Entry level logic analyzer metropolitanto compromise of bandwidth or storage depth indicator and greatly reduce the practicability of this kind of logic analyzer Saleae through USB real time transmission for example using PC memory to store data a good solution to the problemof the depth of the storage but because of the USB bandwidth limited the highest can reach 200 300 MBPS sampling bandwidth Open the Workbench Logic sniffers adopted FPGA internal BRAM as storage space also have a 1 6 Gbps sampling bandwidth but only 216 kbit storage depth Package included 1 x DSLogic Logic Analyzer
