DRV8833 2 Channel DC Motor Driver Module Board 1.5A 3V-10V

Specicications Input voltage 3 10VSize 18 5 16mmSingle H bridge output current 1 5A can drive 2 DC geared motors Built in overcurrent protection short circuit protection undervoltage lockout and overtemperature protection With low power sleep mode Uses It can drive DC motors up to 1 5A and 4 wire stepper motors Instructions for Use ULT low level is sleep mode need to disconnect the J2 short solder joint behind the module OUT1 0UT2 is a 1 way H bridge and the corresponding control is IN1 IN2 OUT3 0UT4 is the second H bridge and the corresponding control is IN3 IN4 EEP is the protection output and is not used by default VCC is a voltage input of 3 to 10V GND ground Package Included 1 x DRV8833 2 Channel DC Motor Driver Module
