DMA860H 57 86 Stepper Motor Driver 200KHz 18-80V AC DriverController 7.2A Driver

Feature: *Runs Smoothly: This stepper motor driver ensures smooth at low medium and high speeds providing a quiet and efficient performance. *Advanced Technology: With built-in -segmentation technology this stepper driver achieves high segmentation effects even at low segmentation settings. *Versatile Usage: Suitable for various scenarios this motor driver utilizes 32-bit technology to meet the application needs of different environments. *User-Friendly: Equipped with an integrated parameter auto-tuning function this CNC controller simplifies the setup process by automatically generating operating parameters for different motors. *High Efficiency: The DMA860H stepper motor controller offers high efficiency and low noise making it an Choices for precise and reliable motor control. Specification: Part Name: Stepper Motor Driver Color: Black material: engineering plastics Model: DMA860H Can drive 4 6 and 8-wire two-phase stepping motor For Nema23 Nema34 Nema42 Stepper Motor Voltage input: 18-80VAC Maximum current: 7.2A resolution: 0.1A Microstep: 400-51200 Signal input: differential/single end pulse/direction or double pulse Pulse response frequency: 200KHz Occasion: Can not be placed next to other heating equipment to avoid dust oil mist corro-sive gas humidity is too big and strong vibration place prohibit flammable gas and conductive dust; Temperature: 0-50℃ Humidity: 40-90% RH Vibration: 10-55Hz/0.15mm Storage temperature: -20℃~65℃ Size: 151*97*52mm Weight: 570g Package Contents: 1*Stepper Motor Driver Note: 1. When VCC=5V is connected in the figure no series resistance is required at the signal end; When VCC=12V the signal end needs resistance of about 1K in series R=1K/ 0.25w; When VCC=24V the signal end needs resistance of about 2K in series R=2K/ 0.25w. 2. Drive internal 270Ω resistor
