DL-20 CC2530 Wireless Transmission Serial Port Module 2.4G Wireless Transmitting and Receiving

Feature Default setting baud rate 9600 point to pointWiring sequence Rx is connected to Tx Tx is connected to RxVoltage range 3 0V 5 5V TTL level adaptiveButton configuration Use the onboard buttons to set up you can modify the channel baud rate and working mode of the module Project nameNumerical valueProduct numberDL 20Chip selectionCC2530F256RHARworking frequency2400 2450MHzTransmit power4 5dBmTransmission rateUp to 3300BpsTransmission distance250 meters outdoor unobstructed environment test Operating Voltage3 0V 5 5VWorking currentLess than 30mASupport working modePeer to peer working mode broadcast working modeCommunication InterfaceUART serial port supports 8 baud rates Working channel2400 4800 9600 14400 19200 38400 57600 115200 Receive spiritual respect16 channel divisions in accordance with the IEEE 802 15 4 protocolPoint to point bit error rate 97dBmBroadcast bit error rate0 00 Antenna interface0 50 Operating temperatureBuilt in PCB antennaSize 40 C 80 CPackage includes 1 x Wireless Transmission Serial Port Module
