DIY XR2206 Function Signal Generator Kit Sine Triangle Square Output 1HZ-1MHZ

Feature Voltage supply 9 12V DC InputWaveforms Square SineTriangleImpedance 600 Ohm 10 Frequency 1Hz 1MHzFrequency amplitude adjustableFive digit precision resolutionIt has coarse fine frequency adjustmentWide range power supply can use an external power supply 9 12V or 9V batterySINE wave Amplitude 0 3V at 9V DC inputDistortion Less than 1 at 1kHz Flatness 0 05dB 1Hz 100kHzSQUARE wave Amplitude 8V no load at 9V DC inputRise Time Less than 50ns at 1kHz Fall Time Less than 30ns at 1kHz Symmetry Less than 5 at 1kHz TRIANGLE wave Amplitude 0 3V at 9V DC inputLinearity Less than 1 up to 100kHz 10mANote This version does not includes the housing Instruction Click to openPackage includes 1 x XR2206 Function Signal Generator DIY KitFinished reference picture Package does not includes the transparent shell Signal 1MHZ
