DIY Smart Car Kit Infrared Remote Control Car Infrared Receiver MCU Electronic Production Kit

Description Kit Name Infrared Remote Control Car KitDimensions 106 80mmBoard material single side 1 6mm FR 4 sheetSupply voltage 5VNumber of LEDs 3 5mm Red LEDs1 Printed on the PCB with various components silk screen marks please refer to the silk screen mark soldering2 The resistance is not divided but there are different resistance values Please pay attention to distinguish when soldering3 Electrolytic capacitor LED is divided into positive and negative poles long legs are short legs are 4 When connecting the power cord to the terminal block pay attention to distinguish between positive and negative poles do not reverse Package included 2 x 10 ohm resistor R3 R4 2 x 51 ohm resistor R5 R6 1 x 200 ohm resistor2 x 3 3k ohm resistor R1 R2 1 x 10k ohm resistor2 x 9012 transistor Q1 Q2 3 x 5mm Red LED D1 D3 1 x 470uf 25V capacitor1 x IC STC15F104W1 x 8P IC socket1 x battery socket1 x Double sided tape1 x M5 30 screw2 x motor1 x remote control1 x receiver1 x button switch1 x M5 Hex Nut1 x M5 Cap Nut2 x M2 10 screw2 x wheel1 x PCB board
