DC12V 1CH 315/433MHz Wireless Time Delay Relay RF Remote Control Switch Receiver

Instructions Working output way 1 Jog Non Latched Press one button is Working ON Loosen your finger on the same button is Stop OFF One channel switch need one buttons remote control 2 Self lock Self Latched Press one button for one time is working ON Press the same button again is stop OFF One channel switch need one buttons remote control 3 Inter lock Latched Press one button is working ON press another button is stop OFF One channel switch need 2 buttons remote control Learning 1 Press the B key once the LED will go off press the button of the remote control the LED of the control panel will blink three times in succession to learn the code successfully Operating Mode Description 1 Set the jog output Unplug the jumper cap2 Set to self lock output use the short jumper pin on the board to connect 1 2 with the middle pin 3 Set the interlock output Connect the 3 4 pin to the middle pin with the jumper cap short pin on the board Delay settings 1 press the button A key once then press the learning code B key press once to set the delay time of one second press the second time to set the delay of two seconds three times for the set delay time of three seconds After the completion of the control panel by pressing the A key to confirm the delay time off this time whether it is jog or self locking interlock status is the delay off function 2 the delay control panel can be set free 1 99 seconds according to your own needs Clear Press the learning button
