DC-DC DC-AC Pure Sine Wave Inverter Generator SPWM Boost Driver Board EGS002 EG8010(Module with LCD)

5V single power supply. Pin set up four kinds of pure sine wave output frequency: fixed frequency 50 hz pure sine wave; 60 hz fixed frequency pure sine wave; 0-100 hz pure sine wave frequency is adjustable; 0-400 hz pure sine wave frequency is adjustable. Unipolar and bipolar modulation. Comes with deadband control pin set up 4 dead time: 300nS dead time; 500nS dead time ; 1.0uS dead time ; 1.5uS dead time External 12MHz crystal oscillator. PWM carrier frequency 23.4KHz. Voltage current real time temperature feedback. Overvoltage undervoltage overcurrent and overheating protection. Soft-start mode pin setting the response time of 1S. Serial communication to set the output voltage frequency and other parameters External. External serial port 128 * 32 LCD module 1602 display the voltage frequency temperature and electric current of the inverter and other information. Material: Plastic + Metal colour: As shown Package Contents: 1 x Module With Display Only the above package content other products are not included. Note: Light and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
