DC 9V-60V 20A Pulse Width Modulator PWM Motor Speed Control Switch Controller

Details: *DC 9V-60V Pulse Width Modulator PWM Motor Speed Control Switch Controller *Suitable for the DC motor (or DC load) within 20A *It with metal shell and connective label very easy to install and use *Potentiometer with adjust speed switch function and button switch function *Connection mode: Red Line: Power + Black Line: Power Blue Line: Motor + Green Line: Motor *Input supply voltage: DC 9V-60V *Max. current: 20A *Sustained current: 18A *PWM frequency: 25KHz *Adjustable speed range: 0%- *Speed adjustment way: Potentiometer *Output voltage: Linear under load *Speed control type: Basins *Wiring: Black/Green(Negative) Red/Blue (Positive) Operating instruction: (Before you attempting to wire the controller make sure power is off) 1. Connect wires refer to the wiring diagram 2. Turn on the power 3. Adjust the potentiometer Package Contents: 1*Speed Controller Switch Note: The real color of the item may be slightly different from the pictures shown on website caused by many factors such as brightness of your monitor and light brightness.
