DC 6V To 30V One Way Relay Module Delay Power Off Disconnection Trigger Delay Cycle Timer Circuit Switch

Parameters Operating voltage DC 6V 30V supports micro USB 5V Trigger signal source high level trigger 3V 24V signal and systematically improve the systems anti interference ability also short circuit altogether Output capability can control equipment that within DC 30V 5A or AC 220V 5AStatic current 20mAWorking current 50mAService life more than 100 000 timesWorking temperature 40C to 85CSize 6 2 3 8 1 7cm length width height Relay enable mode 1 ON the relay is allowed to turn on during the OP conduction time 2 OFF the relay is disabled and always closed 3 Short press the STOP button on the main interface to switch between ON and OFF The current state will flash and then return to the main interface this function is an emergency stop function one touch disconnected relay Sleep mode 1 C P sleep mode no operation within five minutes the digital tube automatically shuts off the display and the program runs normally 2 O d normal mode the digital tube is always on display 3 Press and hold the STOP button for 2 seconds and release it to switch between the C P and O d states The current state will flash and then return to the main interface Operating mode P1 after the signal is triggered the relay turns on the OP time and then turns off during the OP time the following operationP1 1 signal is invalid againP1 2 signal triggered againP1 3 the signal triggers a reset again the relay opens and the timer stops P2 for the trigger signal a
