DC 24V 315/433MHz Universal Wireless Remote Control Switch 1CH Relay Receiver Module With Case

Technical Data:Input Power:DC24VStandby Current:5MARF Frequency: 433MhzRF working mode:superheterodyneReceive sensitivity: 97dbmTransmitting distance:100m ( open space)Decoding mode:MCU software decodingRemote storage:25pcsSupport remote type: Learning code, Fixed code(Rolling code can be design)Working mode:Momentary, Toggle, Latching Time delay (5s ,10s ,15s )Wiring type:fixed terminalOutput Terminal :NO , NC , COMDmension of PCB:35*30*18mm (L,W,H)Wiring diagram 1:+V : 24V + input ;- V: 24V - input ;NO: Output , normal open;COM:Output , common ;NC: Output , normal close;Working Mode:Momentary: Push the remote button , the relay connects, release the remote button , the relay dis-connects.Toggle: Push once the remote button , the relay connects , push twice the remote button , the relay dis-connects .Latching: Push the remote button A, the relay connects, push the remote button B, the relay dis-connect.Tiem delay mode : Push the remote control button , the relay connects , from when release the remote button , after 5s or 10s or 15s , the relay disconnect automatically .Clearing the code:1. Push the learning button on the receivers for 8 times , the codes will be cleaned .2. After clearning the code, all the remote control cannot work any more.Learning the code :(momentary)1. Push the learning key on the receiver once time , it comes into momentary setting mode .2. Wait for a moment , the LED will be off , it comes into learning state .3. Push the remote button , LED ind
