DC 12V Mini LCD Digital Microcomputer Control Power Timer Switch

LCD Digital Microcomputer Control Power Timer Switch Time Relay Description: Condition: 100% Brand New Color: White Quantity: 1 pc Rated Voltage:12V DC Full Time Range:1Min-168Hours Contact Capacity: 16A(8)A,250V AC Resistance load: 16A Inductive load: 8A Internal battery:1.2V/40mA(rechargeable batteries) Operate Temperature:-10~+40C Programmable:17times(week or day) Minimum interval:1 minute Dimensions:approx.60x60x32mm English Instructions included Key Button: clock,timer,day,h+(setting the hours),m+(setting the minutes),manual override,reset Tips: 1.Before starting the program, the timer should be charged for at least 5 minutes as the inbuild battery may be of no battery; 2.Before setting the program, press the key button reset, to clear the memorize data for the new instructions; 3.After the program is made, please insert the timer to the plug. Then connect the electric appliance to the timer; 4.The on and off can be set eight times each day, which can be set as follow: - First option,Sunday; - Second option: from Monday to Friday - Third option: Saturday and Sunday(weekend) - Fourth option: from Monday to Saturday(working days) - Fifth option: Monday,Wednesday,Friday - Sixth option: Tuesday,Thursday,Saturday - Seventh option: from Monday to Wednesday - Eighth option: from Wednesday to Saturday Notice: 1. Shown on the Instruction Manual is "12V Wiring diagram". 2. The "POWER" should connect DC 12V power.Never connect any other power on.The other side can depending on your need. 3. If want to connect 0-250V electrical equipment.Wiring is depending on "0-250V Wiring diagram". 4. No matter which Wiring diagram.The "POWER" only allow to connect DC 12V power. 5. Power"-" is not meaningful,custom-made voltage is DC12V. Package Included: 1 x Control Power Timer Switch 1 x English Instructions
