DC 12V Magnetic Latching Impulse Relay Delay Switch Module for UPS Battery Motor LED IP Camera

Description Working voltage DC 12V 10 15V Working current 7 8MA Digital Tube is OFF Working current 28 30MA Digital Tube is ON Relay switching current 45MA only lasts 0 3 seconds Load current AC 250V 10A DC 30V 10A0 1 seconds 270 hours between adjustable18 functions can be selected Function compatible with CE030 FRM01 Relay Module D1 LED Relay status indication ON relay is on OFF relay is offPWR LED Input indicator It will flash when power on or trigger Size 76 x 40 x 20mmWeight 28gUse must read 1 For more instructions please contact me or search for CE030 FRM01 LR43A01 on GOOGLE Their functional parameters are the same 2 Energy saving is relative to ordinary relay modules 3 In the working state click the SET button to close the digital display and click again to open the digital tube display 4 Press and hold the NUM button for 4 5 seconds After 10 seconds enter the energy saving mode Press and hold the NUM button again for 4 5 seconds to exit the energy saving mode this function can only be set when the digital tube is lit Typical applications Automotive electronicsIndustrial automation and controlIndustrial equipmentMotor LED PLCIP Camera PTZ CCTVUPS Uninterruptible power supplySmart HomeEmergency lightingMCU development boardToy carHome lighting systemRemote control switchRemote lockingSmart Home Home AutomationLED lightingFluorescent lampDC MotorFluorescent lampAutomotive electronicsConnections Module control side there are 3 wire i
