DC 12V-36V 15A 500W Brushless Motor Controller BLDC Driver Board Stall Over-current Protection

Specification Operating voltage DC 12V 36VOperating Current 15ADriver Power 500WSpeed Voltage 0 1V 5VOperating Temperature 40 85°CHumidity 90 RHStall protection YesEnable Control YesOver current protection YesSteering control YesSpeed control signal YesSize 63 x 42 x 17mm L x W x H Probe size 3mm length fixing hole center distance 57mm width fixed hole center distance 36 5mmPower terminal Out VCC positive power supply GND negative one MC motor phases W MB motor phases V MA motor phase U Set for the control side GND control terminal groundVR the governor end 0 5V corresponding to 10 of motor speed 100 ZF reversing control connected to 5V or ground can charge the motor rotation direction M tachometer pulse output depending on the number of motor poles corresponding to the number of pulse per revolution of the output number EL enable control terminal connected to 5V ot ground running then 5V grounding the motor stops 5V 5V control terminalControl terminal for SET 1 The motor speed control wiring methods available potentiometer system speed can also be connected to the MCU control when the potentiometer control wiring the potentiometer middle pin is connected to VR speed port potentiometer connected to both ends of 5V and GND terminal voltage more high speed faster 2 Motor steering control wiring methods you can switch control can also be connected to the MCU control to GND in one direction then in one direction 5V 3 Pulse speed signal h
