DC 12V 1500N 6mm/s Linear Actuator Motor 50mm-500mm Aluminum Alloy IP54 2-20 Inch Linear Actuator

Descriptions This miniature linear actuator is using for industrial agricultural machinery construction clean sweeping vehicles vessels cargo and many other applications It can be replaced by hydraulic pneumatic products ideal for saving energy consumption Specifications MaterialAluminum alloyLoad capacity1500NSpeed6mm sInput VoltageDC 12VStroke Length50mm 100mm 200mm 300mm 400mm 500mmDuty cycle10 Quantity1pcsTechnical Parameters Rated power 20W maximum 30W Push bar Each side contains a travel limit switch When the telescopic bar runs to the top or to the top it will automatically disconnect the electricity The motor will not idle Cut off the power it can be stop at any position with self locking function The push rod is driven by a DC motor with a screw drive The telescopic rod can only be retracted without rotation The motor is positive and negative For example if the positive electrode is stretched and the negative electrode is shrunk the telescopic direction of the rod can be changed by changing it Ambient temperature 20°C to 75°C Standard protection class IP54 Low noise design noise level less than 42dB Please do not disassemble the machine Product features drive other objects to push pull rise drop Product Applications TV lift tables massage beds electric beds medical chairs electric equipment micro devices electric sofas camera frames cameras and more Installation Size 1 The center distance between the two mou
