DAYTON 7AT89 D/D Blower w/ Motor 208-230/460 V

High Pressure Blower With Motor Wheel Dia. (In.) 9 CFM @ 0.000-In. SP - CFM @ 1.000-In. SP # CFM @ 3.000-In. SP 336 77 dBA @ 5 Feet Max. Inlet Temp. (Deg. F) 180 Max. Ambient Temp. (F) 104 Voltage 208-230/460 3 Phase 60 Hz Full Load Amps 1.7-1.8/0.9 Motor HP 1/2 Motor RPM 3450 Motor Enclosure Open Dripproof Motor Frame 48 Shaft Dia. (In.) 1/2 Height (In.) 17 Width (In.) 13-5/8 Depth (In.) 12-3/4 Inlet Dia. (In.) 5 Discharge Height (In.) 3-1/2 Discharge Width (In.) 3-1/2 Features Item: High Pressure Blower Type: With Motor Wheel Dia. (In.): 9 Voltage: 208-230/460 Motor HP: 1/2 Max. Inlet Temp. (Deg. F): 180 Wheel Bore (In.): 1/2 Dimension G (In.): 1/2 Dimension E (In.): 5-5/8 Dimension R (In.): - Motor Frame: 48 Depth (In.): 12-3/4 Dimension T (In.): - Height (In.): 17 Full Load Amps: 1.7-1.8/0.9 Dimension C (In.): 3-1/2 CFM @ 4.000-In. SP: 270 dBA @ 5 Feet: 77 Inlet Dia. (In.): 5 Dimension M (In.): 6-3/4 Rotation: CW CFM @ 6.000-In. SP: - CFM @ 2.000-In. SP: 391 Discharge Width (In.): 3-1/2 CFM @ 3.000-In. SP: 336 Dimension A (In.): 12-1/8 CFM @ 5.000-In. SP: 173 Motor Enclosure: Open Dripproof Dimension V (In.): - Dimension D (In.): 3-1/2 Dimension N (In.): - Wheel Material: Aluminum Wheel Width (In.): 2-13/16 Dimension B (In.): 8 Dimension F (In.): 7 Dimension O (In.): 5 Dimension L (In.): 6-7/8 CFM @ 8.000-In. SP: - Assembled/Unassembled: Unassembled Dimension P (In.): 7-1/2 Dimension S (In.): 6-3/8 Bearing Type: Ball in Motor Dimension H (In.): 6-3/8 CFM @ 1.500-In. SP: - Shaft Dia. (In.): 1/2 Motor RPM: 3450 Housing Finish: Gray Polyester Epoxy CFM @ 0.250-In. SP: - Dimension K (In.): 12-3/4 Phase: 3 Width (In.): 13-5/8 Housing Material: Steel Hz: 60 CFM @ 0.500-In. SP: - Discharge Height (In.): 3-1/2 CFM @ 7.000-In. SP: - Max. Ambient Temp. (F): 104 CFM @ 0.750-In. SP: - Blower RPM: 3450 Agency Compliance: AMCA AIR Dimension X: - Dimension J (In.): 5-3/4 CFM @ 0.000-In. SP: - CFM @ 1.000-In. SP: # Zoro Benefits: 7 000+ Brands. Free Shipping. Hassle Free Returns.
