DAYTON 7A880 Exhaust Vent 42 In

Exhaust Ventilator Belt Drive Yes Drive Package With Motor Included Base Size - Roof Ventilators 50-1/2 in x 50-1/2 in Blade Dia. 42 in Voltage - Roof Ventilators 208V AC/220V AC/440V AC Motor HP 2 Motor Enclosure Design Totally Enclosed Propeller Material Steel CFM @ 0.000-In. SP 23 987 CFM @ 0.125-In. SP 21 470 Sones @ 0.125-In. SP @ 5 Ft. 24 Max. Inlet Temp. (Deg. F) 120 CFM Range 12 446 to 32 495 Roof Mounting Location Base Height (In.) 1-3/4 Features Item - Roof Ventilators: Exhaust Ventilator Drive Type - Roof Ventilators: Belt Drive Drive Package With Motor Included: Yes Base Size - Roof Ventilators: 50 1/2 in x 50 1/2 in Blade Dia.: 42 in Voltage - Roof Ventilators: 208V AC/220V AC/440V AC Phase: 3 Motor HP: 2 hp CFM @ 0.000-In. SP: 23 987 CFM @ 0.675-In. SP: - Bearing Type: Regreasable Pillow Block Motor Voltage: 208/220/440 Motor Enclosure Design: Totally Enclosed Dimension A (In.): 50-1/2 Recommended 12 In. Fixed Curb Item No.: 3AZJ5 Dimension B: 44 1/4 in Drive Type: Belt Max. Operating Amps: - Speed Control: - Sones @ 0.125-In. SP @ 5 Ft.: 24 Adj. 6 3/8 H Roof Curb Stock No.: 3C216 Speed Controllable: no RPM Range: 275 to 718 Dimension D (In.): 38 Dimension A: 50 1/2 in CFM @ 0.125-In. SP: 21 470 CFM Range: 12 446 to 32 495 Mounting Location: Roof Housing Material: Galvanized steel Base Square Size - Roof Ventilators: 50-1/2 x 50-1/2 Motor Hz: 60 Shaft Dia. Propeller End (In.): 1.25 in Dimension D: 38 in Requires: Roof Curb for New Installations Motor HP Range: 1/2 to 5 Base Length (In.): 50-1/2 Assembled/Unassembled: Unassembled Fan RPM: 530 Dimension E: 49 5/8 in Base Height (In.): 1.75 in Dimension C: 20 in Recommended 8 In. Fixed Curb Item No.: - Base Width (In.): 50-1/2 Propeller Material: Steel Overall Dia. (In.): 52 in Drive Package Included: Yes CFM @ 0.500-In. SP: - Item: Exhaust Ventilator Stock No.: 4YY26 Dimension B (In.): 44-1/4 Shaft Dia. Sheave End (In.): 1.25 in Recommended Damper Size (In.): - CFM @ 0.750-In. SP: - Sones @ 0.250-In. SP @ 5 Ft.: 25 Dimension E (In.): 49 5/8 Type: Axial Upblast Overall Height (In.): 38 in Adj. 12 3/8 H Roof Curb Stock No.: 2ZV86 Agency Compliance: UL/cUL 705 Listed Max. Inlet Temp. (Deg. F): 120 Degrees F Recommended Damper Stock No.: - Dimension C (In.): 20 CFM @ 0.250-In. SP: 18 061 Max. BHP: 2.41 hp CFM @ 0.375-In. SP: 11 471 Zoro Benefits: 7 000+ Brands. Free Shipping. Hassle Free Returns.
