DAC Module MCP4725 for Analog Signal Capture Converter Compatible M5StickC ESP32 Mini IoT Development Board Fi

Description DAC HAT is also a type of C HAT specifically design for M5StickC controller Same as DAC unit this is a voltage output DAC converter for stickc It can generate a voltage of 0 3 3V Packed with a DAC converter chip MCP4725 which is low power high accuracy single channel 12 bit buffered voltage output Digital to Analog Converter DAC with a non volatile memory EEPROM Its on board precision output amplifier allows it to achieve rail to rail analog output swing The DAC input and configuration data can be programmed to the non volatile memory EEPROM by the user using the I2C interface command I2C address 0x60Product Features M5StickC CompatibleOutput 0 3 3VSoftware Development Platform UIFlow Blockly Python MCP472512 BitResolutionExternal A0 Address PinNormalorPower DownModeFast Settling Time of 6 s typical ExternalVoltageReference VDD Rail to RailOutputLowPowerConsumptionSingle SupplyOperation 2 7V to 5 5VI2C Interface address 0x60ExtendedTemperatureRange 40Cto 125CPackage Included 1x DAC HAT1x 2 Pin 3 96 Pitch TerminalApplication SetPointorOffsetTrimmingSensorCalibrationClosed LoopServoControlLowPowerPortableInstrumentationPCPeripheralsDataAcquisitionSystemsLinks Datasheet MCP4725Schematic EasyLoaderclick to download EasyLoader1 EasyLoader is a simple and fast program burner Every product page in EasyLoader provides a product related case program It can be burned to the master through simple steps and a series of function verification ca
