Custom Waveform Signal Amplitude Modulation Multifunctional Signal Generator Arbitrary Waves Generator Laboratory For Secondary Development And Programming US 110V EU 220V UK

Custom Waveform Signal Amplitude Modulation Multifunctional Signal Generator Arbitrary Waves Generator Laboratory for Secondary Development And Programming US 110V EU 220V UK Specification: Condition: Item Type: Signal Generator Material: ABSSize: Approx. 240 x 218 x 87mm/9.4 x 8.6 x 3.4in Model PSG9080 Channel 2 Sampling Rate 300MSA / S Waves Characteristics Waves Length 8192 points/channel Waveform Vertical Resolution 14 bits Waves Type Sine waves waves pulse waves duty ratio pulse width and cycle time can be set accurately triangular waves rising ramp falling ramp CMOS waveform DC half waves full waves sine waves Inverse order waves exponential rise exponential fall Lorentz pulse waves multisonic waves random noise waves trapezoidal pulse waves sinking pulse waves amplitude modulation waveform frequency modulation waveform and 99 user-defined waveforms. Frequency Characteristics Sine Waves Frequency Range 1nHz-80MHz Waves Frequency Range 1nHz-30MHz Triangular Waves Frequency Range 1nHz-50MHz Pulse Frequency Range 1nHz-30MHz TTL Digital Waves Frequency Range 1nHz-20MHz Arbitrary Waves Frequency Range 1nHz-50MHz Pulse Width Adjustment Range 5nS-4S Pulse Period Adjustment Range 10nS-40S Minimum Frequency Resolution 1nHz Frequency Accuracy ±5ppm 0-50 degrees Celsius Frequency Stability ±3ppm / 1 year Sine Waves Spectrum Purity Total Harmonic Distortion Less than or equal to 0.5% At 1kHz 5Vpp Signal Characteristics Waves Rise/Fall Time Less than or equal to 10nS Overshoot Less than or equal to 10% Asymmetry Less than or equal to 0.1% Oblique and Triangular Waves Linearity Less than or equal to 1% less than 1MHz Asymmetry Less than or equal to 1% less than 1MHz Pulse Waves Pulse Width 5nS-4S Pulse Cycle Time 10nS-40S Duty Cycle 0.01%-99.99% Rising/Falling Edge Less than or equal to 10nS Overshoot Less than or equal to 10% Arbitrary Waves Waves Length 8192 points 8K points Vertical Resolution 14 bits Minimum Rise/Fall Time Less than or equal to 10nS Overshoot Less than or equal to 10% Arbitrary Waveform Non-Volatile Storage Number 99 Output Characteristics Amplitude Amplitude Range Frequency Less than or equal to 1MHz 1MHz Less than or equal to Frequency＜11MHz 11MHz Less than or equal to Frequency＜60MHz 60MHz Less than or equal to Frequency＜80MHz 2mVpp-25Vpp 2mVpp-10Vpp 2mVpp-5Vpp 2mVpp-3.6Vpp Amplitude Resolution 1mVpp Amplitude Stability ±1%±1 mVpp At 1 kHz > 10 mVpp Amplitude Flatness ±1%0.1dB
