Creativity® ANTCLABS BLTouch V3.1 Auto Leveling Sensor BL Touch Sensor Touch with Bracket for SKR V1.3 Pro Reprap Auto K

Features Main functions and controls of BLTouch are the same as usual auto bed leveling sensor consists of RC servo and micro switch Thus BLTouch can be applied on almost every board BLTouch is fulfilled with simple structure and high precision by using progressively designed solenoid and hall sensor It aims for user convenience and enjoyable printing by adding many smart functions such as self test alarm alarm releaseTouch Switch mode Blue LED for servo signal indicating and Z probe Zmin Testing Hall Sensor Free Bed SelectionBLTouch does not uses either optical nor proximity inductive capacitive sensor BLTouch is controlled by hall effect providing high precision Thus the bed material can be selected freely Specifications Wiring 3Pin Brown GND Red 5V Orange control signal 2Pin Black GND White Zmin Voltage 5VCurrent 15mAMaximum Peak Current 300mACase Material Polycarbonat PC Case Color Semitransparent WhiteCable Length 150mmPCBSoldering RoHS Lead Free Pb Free Item description ANTCLABS Official Web Manualhttps www antclabs com manual Summary BLTouch is an auto leveling sensor for 3D Printers that can precisely measure the tilt of Bed surface It could work with any kinds of bed materials such as glasses woods metals and so on Package included 1 set accessories with bracket Details pictures
