Cooke 100mm T2.0 S7/i Plus Prime Lens for PL Mount
Shoot 35mm, Super 35mm, Full Frame, VistaVision and beyond with the Cooke S7/i Primes, designed to cover the emergent full frame cinema camera sensors up to at least 46.31mm image circle.ConvenientWe have you covered with the ability to shoot in various formats, from 35mm to VistaVision - all with the Cooke Look.ReliableExcellent optical and mechanical performance, control of flare, veiling glare, distortion and spherical aberrations at full aperture.PracticalColor matched to Anamorphic/i, S4/i, miniS4/i, 5/i and Panchro/i Classic lenses.IntelligentSupplied with the next generation of /i Technology for automatic lens metadata capture.
TechnologyThe /I Technology provides cinematographers and camera operators with vital information on lens setting, focusing distance, aperture and depth-of-field, hyperfocal distance, serial number, owner data, lens type and focal length in both metric and footage measurements. For zoom lenses, the zoom position is displayed.
Handcrafted InnovationGrinding & PolishingTraditional polishing techniques are used to achieve the highest level of precision.MetrologyMore insights and measurements are taken than ever before to ensure superior quality.Coating & CementingMinerals are evaporated at a high temperature in a vacuum to create a thin film on the glass.EdgingEdging is carried out to ensure that glass diameters are perfectly round.Cleaning & AssemblyLenses are meticulously tested, checked, modified, cleaned and rechecked.Features:Optical DesignThe optics are designed to give maximum performance at full aperture with superior control of flare, distortion and spherical aberration.Focus ScalingLarge, clear numerals on both sides of the focus barrel benefit the focus puller when shooting under difficult lighting conditions. Plus the Entrance Pupil position is engraved on the lens./i ElectronicsAccessible via contacts in PL mount that sync with /i compatible cameras.
CompatabilityAll Cooke S4/i Primes have a common fixed front diameter of 110mm, (except for 12mm, 150mm, 180mm, 300mm) with a focus drive gear of 140T x 0.8 mod and an iris drive gear of 1147 x 0.8Color BalanceAll S4/i prime lenses are color balanced, color-matched and compatible with Cooke 5/i, miniS4/i and Anamorphic/i.External FinishA scratch resistant PTFE hard anodised finish is provided on all Cooke lenses, providing a durable, hard-wearing surface to meet the most demanding environmental conditions.ApertureAll S4/i primes have a true T2 aperture and cover Super 35mm format.IrisAn eight-leaf linear module iris assembly is fitted into S4/i primes with an aperture range of T2 to T22.Index MarksEvery index mark is labelled. More detailed markings allow for more detailed focus control.
Focus MovementOur Academy Award winning cam-style focus movement coupled with the added benefit of a large lens barrel diameter, has allowed for an increased number of focus markings, particularly at close focus. Spherical aberration has been controlled throughout the range of focal lengths to eliminate compensation of changes in back focus with aperture. A four-point contact bearing provides a smooth positive backlash-free movement.Weight/Size RatioThe lenses are designed for all shooting applications, including handheld and Steadicam, providing comfortable balance ratio with the latest compact cameras.
Camera MountsCooked Hardened PL Mount with /i Technology contacts.Reliability and ServiceThe lenses are designed for all shooting applications, including handheld and Steadicam, providing comfortable balance ratio with the latest compact cameras.
