Conector AmpSeal macho 23 vìas gris PCB 90°

Código ErreBi: 57177 Código productor: 776087-4 Productor: TE/Connectivity Characteristics of the product type Connector and Housing Type: Female Terminal Housing Connector system: cable-to-board, cable-to-device Sealable: Yes Hybrid connector: No Main lock function: integrated into the housing Configuration features Number of positions: 23 Number of lines: 3 electrical characteristics Operating voltage (VAC): 250 Nominal voltage architecture (V): 12, 24, 42, 48, 80, 90, 125, 240 Characteristics of the body Body Material: Other Cable exit angle: 90° Main product color: natural Contact characteristics Diameter of the coupling pin: 1.3 mm [.051 in] Mechanical attack Coupling Alignment Type: Polarized Tearproof: No Terminal position guarantee: Yes Mounting function: without Housing features Centerline (pitch): 4 mm [.157 in] Dimensions Row-to-row spacing: 4 mm [.157 in] Product Height: 34.6mm [1.362 in] Product length: 27.4 mm [1,079 in] Product width: 33.6 mm [1,323 in] Terms of use
