Features
Distributes 1 SDI input to 2 SDI outputs simultaneously.
Single unit can transmit up to 120m/390ft (Belden 1694A).
Re-clocking function capability---unlimited repeater connection.
Support SDI Standard :SD-SDI,HD-SDI, 3G-SDI.
Data Rates: 270Mbps(SD-SDI), 1.485Gbps (HD-SDI), 2.97Gbps (3G-SDI).
Signal Type: SMPTE 292M, SMPTE 259M, SMPTE 424M.
DC 5V~12V (Power consumption less than 2W).
Specifications
Name
SD/HD/3G-SDI 1 to 2 Distribution Amplifier & Repeater
Model
LM-SDI-102
Re-clocking Function
Yes
SDI Standards
SD-SDI, HD-SDI,3G-SDI
HD/SD-SDI Detection
Auto
Supported Protocols
SMPTE 259M, SMPTE 292M, SMPTE 424M
Data Rates
270Mbps(SD-SDI), 1.485Gbps (HD-SDI), 2.97Gbps (3G-SDI)
Video Support
480i @60hz, 720p@50 / 59.94 / 60hz, 1080i @50 / 59.94 / 60hz, 1080p @23.98 / 24 / 25 / 29.97 / 30 / 50 / 59.94 / 60hz
SDI Signal Type
SMPTE-292M, SMPTE-259M, SMPTE-424M
Output Impedance
75 ohms
Cable Equalization
HD-SDI up to 120m, SD-SDI up to 200m, Unlimited repeater connection
Audio Sampling rate
48Khz
Impedance
75 ohms
Input
1 x BNC [SDI]
Output
2 x BNC [SDI]
Power Adapter
5V~12V DC
Power Consumption (Max)
2W
Operating Temperature
0℃ ~ 40℃ / 32℉ ~ 104℉
Storage Temperature
-20℃ ~ 60℃ / -4℉ ~ 140℉
Relative Humidity
20~90% RH (no condensation)
Housing Material
Metal Case
Product Size
10.5 x 8 x 3 cm
Product Weight
200g
Package Size
21 x 15 x 6 cm
Package Weight
530g
