Cnc Engraving Machine Parts Automatic Tool Setting Gauge High Accuracy 6-Lines NO CNC Engraving Machine Parts

cnc engraving machine parts Automatic Tool Setting Gauge High Accuracy 6-Lines NO CNC Engraving Machine Parts Specification: Item Type: Automatic Tool Setting GaugeOutput Mode: B: NO normally open Stroke: 5mm Repeatability: 0.001mm Electric Shock Life: 3 million times Protection Structure: IP67 Contact Force: 1.5N Material of the Contact Area: Hard-bonding Housing Material: Ground 4S Protection Tube: 1 meters minimum bending radius R25 Cable: 5 meters oil resistant 6-core Electrical Aspects: 1. Contact rating DC24V ? 10% 20mA maximal 2. When the body of the machine is grounded use the tool setter to install it on the side of the ground wire. 3. For the tool setting instrument with LED pay attention to the connection + - when connecting. Recommended value is 10mA resistance load. 4. For the output structure when the interface unit is attached please read the user manual Package List: 1 x Automatic Tool Setting Gauge Note: 1. Please control the tool setting speed at 50 ~ 200mm / min 2. Operating ambient temperature range: 0 degrees Celsius ~ 80 degrees Celsius 3. Please control the voltage at DC24V and the current below 20mA 4. Please note that the old and new type of the product will be sent randomly and make sure you will not mind before ordering.
