Cloned Duet3 6HC Mainboard + Duet3 3HC Expanding Board for BLV Cube 3D Printer

Duet3 6HC motherboard features 1 Powerful 32 bit processor ARM Cortex M7 300Mhz 2 Dedicated high speed bus connection to single board computer e g Raspberry Pi for user interface and plug in 6 high capacity Trinamic 5160 stepper drivers running up to 4 45A RMS with 6 3A peak including firmware control of all functions up to 256 microsteps StallGuard 2 and StealthChop23 Supports next generation Duet3D expansion boards smart tools and custom plug ins for the CAN FD bus The initial goal is to support up to 8 3 channel expansion boards another 24 stepper channels 4 10 variable current capacity PWM outputs to support one high current heating bed 3 extruders and 6 fans 5 9 IO ports for end blocks probes filament monitors and other sensors 6 4 thermistor PT1000 inputs and supports 4 PT100 thermocouple inputs via optional daughter boards 7 Connect to the on board web interface via a PC tablet or smartphone on the same network 8 Set up the printer and update the firmware via the web interface 9 Supports all common 3D printer geometries10 Support multiple Z probes including DC42 s IR Z probe and Duet3D Smart Effector for incremental printers Duet3 3HC expansion board features 1 Dedicated 32 bit processor ARM Cortex M4F 120 Mhz 2 CAN FD bus connection to Duet 3 main board This allows the connection of many expansion boards The initial goal is to support up to 8 x 3 channel expansion boards another 24 stepper channels 3 3 Next generation Trinami
