Cloned Duet 2 Maestro Advanced 32bit Motherboard Mainboard With 4.3inch PanelDue Touch Screen Controller For 3D Printer

Description The Duet 2 Maestro is an advanced 32 bit electronics for the control of 3D printers and other CNC machines it is part of the second generation family of Duet 3D electronics controllers that includes the Duet 2 WiFi and Ethernet As part of the Duet 2 family the Maestro share core similarities with the other Duet 2 boards however there are key differences Features highlights include open source RepRapFirmware 120MHZARM processor and Trinamic Silent motor drivers with unprecedented 256 microstep resolution Connectors are not included Duet 2 Maestro Features Input Voltage 12V to 28V Voltage Monitoring Monitors Vin Power Loss Recovery Supported Processor 120MHZ Arm Cortex M4 ATSAM4S8C Motor Drivers 5 X Trinamic TMC2224 providing up to 1 6 A current per motor and 256 microstepping Endstop Support 5 X can be with open source filament monitoring add ons Heated Bed Support Up to 18 A Current Temp Sensor Support 4 X capable of thermistor or direct PT1000 support Fan Support 3 X Voltage controlled fans 1 X always on Selectable 5V Vinput Servo Support 1 X Additional Motor Support 2 X TMC stepsticks may be added Ethernet Support 100mbps Wired Ethernet WebInterface Included LCD TouchScreen Support Compatible with PaneldDUE in future firmware update Compatible Firmware RepRapFirmware DC42 ForksClick for more info Package included 1 x Motherboard1 x 4 3inch PanelDue Touch Screen
