Clamp Leaker 0mA-60.0A 4-Digit LCD Display Leakage Current Tester Data Hold Overflow Display With Bag For Testing

Clamp Leaker 0mA-60.0A 4-Digit LCD Display Leakage Current Tester Data Hold Overflow Display with Bag for Testing Specification: Item Type: Leakage Current Tester Material: ABS Model: ETCR6000B Measurement Function: Automobile DC dark current leakage current etc. other AC and DC current leakage current measurement Power Supply: 1 x 6F22 9V Battery 100 hours of continuous use Battery Not Included Test Method: Clamp-on CT non-contact measurement Jaw Size: Approx. 16x18mm / 0.6x0.7in Range: 0mA-60.0A Resolution: 1mA Accuracy: ±2%Rdg±5dgt 23 degrees Celsius ±5 degrees Celsius Below 75% Display Mode: 4-Digit LCD Display Sampling Rate: 2 Times/Sec Frequency Response: AC 45Hz-400Hz Polarity Indication: Automatic recognition when DC current is detected display - sign Wire Position: The wire to be detected is at the center of the jaws Shifting: Fully automatic switching Line Voltage: 600V and below line test USB Interface: With a USB interface the stored data can be uploaded to the computer saved and printed Communication Parameters: Baud rate 9600 data bit 8 stop bit 1 parity bit NONE Support Functions: Data retention overflow display automatic shutdown battery voltage Working Current: 10mA Working Temperature and Humidity: -10 degrees Celsius -50 degrees Celsius ; below 80% Limit Temperature Error: -10 degrees Celsius -0 degrees Celsius and 40 degrees Celsius -50 degrees Celsius the maximum error increases by 2%rdg Storage Temperature and Humidity: -10 degrees Celsius -60 degrees Celsius ; below 70% Insulation Strength: AC 3700V/rms between core and box How to Use: Get the product open the back cover with a tool install the battery and the user can adjust the measurement range and then you can use the measurement. The right knob is zeroed which has strong anti-interference and better calibration to . HOLD is the data holding key. It is very convenient to measure by simply putting the wire into the jaws. Package List: 1 x Leakage Current Meter Battery Not Included 1 x CD 1 x USB Cable 1 x Manual 1 x Bag Note: 1. Please allow 0‑1 inch error due to manual measurement. Thanks for your understanding. 2. Monitors are not calibrated same item color displayed in photos may be showing slightly different from the real object. Please take the real one as standard.
