China low price YB1-25 Rotary Vane Pump for Metal Cutting Machine
sku: 32369103821
ACCORDING TO OUR RECORDS THIS PRODUCT IS NOT AVAILABLE NOW
$78.96
Shipping from: China
Technical Details
| Application: | Metal cutting machine tools, hydraulic machines, plastic Mechanical |
| Displacement: | 25ml/r |
| Fuel: | electric |
| Inlet pressure: | 0.02-0.025MPa |
| Model Number: | YB1-25 |
| Power: | 3.3kw |
| Pressure: | 6.3MPa |
| Pressure fluctuations: | ±2 |
| Rated pressure: | 63kg |
| Speed: | 960r/min |
| Standard or Nonstandard: | Standard |
| Steering: | Clockwise direction (the direction from the shaft) |
| Structure: | Gear Pump |
| Suction height not more than: | 500mm |
| Theory: | Rotary Pump |
| Usage: | Low pressure hydraulic system |
| Volumetric efficiency: | ≥90 |
