Chihai Motor CHF-FK180SH-12160 DC 6V 12V Micro Motor DC 180 Motor with AB Phase Encoder

Specifications ModelCHF FK180SH 12160 ABHL DC Encoder MotorCHF FK180SH 12160 ABHL DC Encoder MotorVoltageDC 6 0VDC 12 0VNo load speed7800 rpm16000 rpmNo load current0 10A0 14AAT stall torque10 55 mN m20 92 mN mAT stall current ≥2 1 A≥4 0AAT MAXIMUM EFFICIENCYSpeed 6282 rpmCurrent 0 41ATorque 2 05 mN mOutput Powe 1 4WEfficiency 54 39 Speed 13316 rpmCurrent 0 69ATorque 3 51 mN mOutput Powe 4 9WEfficiency 58 73 AT MAXIMUM OUTPUTSpeed 3900 rpmCurrent 0 91 ATorque 5 27mN mOutput Powe 2 16 WEfficiency 39 61 Speed 8000 rpmCurrent 1 79ATorque 10 46 mN mOutput Powe 8 77 WEfficiency 40 73 Specifications NameEncoders ConflgTypeAB Dual Phase Incremental encordPulse Outputs of RotationBasic pulse 11PPR x gear reduction ratioHolzer Power Supply VoltageDC 3 3V DC 5 0VBasic FunctionWith the pull up shaping resistor the single chipmicrocomputer can be usedEncoder Interface TypePH2 0 Standard wiring Output Signal TypeAB phaseResponse Frequency100kHzBasic Pulse Number11 PPRPoles of Magnetic Ring22 poles 11 pairs of poles Feature ▲ AB phase dual hall encoding board with built in pull up resistence ▲ Metal gear reduction mechanism high strength stable transmission high efficiency and high torque ▲ Frequent blocking or frequent start up and upset are not recommended in the process of use which will significantly reduce the service life Package Included optional 1 x Chihai Motor
