Chihai CHW-GW4632-BLDC2838 DC 12V/24V Brushless Worm Reduction Gear Motor

Descriptions: Chihai CHW-GW4632-BLDC2838 DC 24V brushless worm reduction geared motor Specifications: Brand: Chihai Model: CHW-GW4632-BLDC2838 DC Brushless Worm Reduction Geared Motor Type Rated voltage Max. input power Ratio No load Rated Blocking Current Speed Torque Speed Current Current Torque A DC12.0V 9.5W 1:158 280mA 38rpm 13.0Kg.cm 1.3N.m 30rpm 0.7A 3.0A 1.50Kg.cm B DC24.0V 25W 350mA 75rpm 20.0Kg.cm 2N.m 60rpm 1.2A Note 1. Note: 1. The blocking current exceeds the limit current of the driving MOS tube, please do not use it for blocking, ensure that the current is less than 2.5A. 2. Because the gear bearing capacity is only 3N.M instantaneous load, the long-term operation mode should be used within 2N.M, and the instantaneous load should be lower than 3N.M. Do not block or start frequently. Motor Terminations: No. Signal I / O Specifcations Note 1 Vm (red wire) IN DC12V10% Power 2 FG (green wire) VOH OUT 6.0V max. Hall signal pulse outputs VOL 0.5V max. FG Singnal Current 2mA Pulse Outputs of Rotation 3 pulse/ cycle 3 CW/ CCW Control (yellow wire) Input Voltage Rotation IN 0V/ 5V High-motor CCW Low-motor CW VIH 2.0V min. or open VIL 0.5V max. 4 GND (black wire) OUT Power ground Power ground 5 PWM Control (blue wire) 60K Max. Typical (10K-30K) Input Voltage Range IN 0V/ 5V 10K-30K High-motor OFF Low-motor ON VIH 2.0V Min. or open VIL 0.5V Max Features: - Two types to meet your different needed; - Worm gear and worm deceleration mechanism. Package Included: 1 x DC Brushless Worm Reduction Geared Motor More Details:
