ChiHai CHW-4058-3162 Double Shaft Metal Gear Motor DC 12/24V 110/220RPM Worm Gear Reducer Motor

Description ChiHai CHW 4058 3162 31ZY DC 12 24V 110 220RPM permanent magnetic worm gear reducer motor fits for intelligent car engine Specification Model CHW 4058 3162 31ZY Outer Diameter Size 40 x 36 x 117mm excluding axle and wiring terminals Axle Diameter Axle Output Diameter 8mm D Type D Thickness 7 0mm Output shaft length 15mm D length 13mm long both sides output shaft Type 80 Type input motor Working Voltage V DC 12 0 DC 24 0 Max power W 20 35 Reduction ratio1 361 72No load current mA 400200No load speed RPM 220110Rated torque kg cm 8 016 0Rated speed RPM 17587Rated current A 1 61 2Plugging torque kg cm 25 050Blocking current A 6 55 0Features 1 Pure copper winding wireThe rotor is made of pure copper with low resistance and high conductivity which improves the motor torque 2 D axis fontD shaped shaft more convenient to install not easy to slide save installation time 3 All metal structureWear resistant torsion resistant long service life smooth operation 4 Reducer adopts ball bearing structureLow friction resistance low noise long service life fast heat dissipation high precision and strong composite capacity 5 The service life in the nominal torsion range is more than 2000H delivery of the maintenance Ultra twist life is going to be drastically reduced 6 frequent blocking or frequent start up and upset are not recommended in the process of use which will significantly reduce the service life Package Included 1 X
