Ccdes Wind Generator Controller Household Waterproof Wind Power Regulator 1000W 48V Waterproof Wind Charge Controller Wind Power Charger Regulator

Feature: 1. Reliable Modular Design: The rectifier and brake circuit parts of the controller adopt an integrated modular design and the performance of the entire system is safe and reliable. 2. Sealing and Waterproof Performance: Adopts a sealed and waterproof design and has an IP67 protection level which can be used in environments with high air humidity and salinity or water accumulation. 3. Heat Dissipation Effect: The multiple edges design increases the heat dissipation area and the aluminum shell is and easy to dissipate heat. 4. Can Charge the Battery: The controller can control the wind to automatically charge the battery and provide automatic braking and recharging functions. 5. With Multiple Protection: With multiple protections such as waterproof strong wind anti reverse connection temperature compensation etc. 6. Engineering or Household Use: Mainly used wind power generation system wind and solar power generation system can be used engineering or household. Specification: Item Type: Wind Generator Controller Product Model: FW10-48 Rated Battery Voltage: 48V Wind Generator Rated Power: 1000W Wind Generator Braking Voltage: 60V Wind Generator Recover Voltage: 54V Brake Start Current: 30A Quiescent Current: ≤10mA Protection Level: IP67 Working Temperature: -35℃-+75℃ Shell Size: Approx. 150 x 132 x 48mm / 5.9 x 5.2 x 1.9in Package List: 1 x Wind Generator Controller Note: 1. Confirm that the output voltage of the wind is consistent with the rated voltage of the battery. 2. Connect according to the wiring diagram first connect the positive and negative poles of the battery and then connect the 3 phase voltage output of the wind . 3. Please carefully follow the user manual to connect the battery and wind generator to the controller. If you do not connect the battery and the wind generator as required the reverse polarity or the wrong position will cause damage to the system components. 4. It is strictly forbidden to connect the controller directly to the wind generator before connecting the battery! How to use: 1. Respectively connect the + and ‑ of the battery to the red wire of the controller and the negative pole black wire of the battery. 2. Respectively connect the green wire of the controller 3 phase AC voltage input wire to the 3 phase voltage output wire of the wind generator.
