Cambo WTSA-890 Tilt/Swing Lenspanel, 90mm Rodenstock HR-Digaron-SW Lens, Spacer

The WTSA-890 Lenspanel is dedicated to the use with Digital Backs with sensor activated electronic shutter and has a Rodenstock 5,6/90 HR-SW Digaron lens with Aperture Only mounted in a helical focussing mount. This version has a split back focal length, existing of a shorter lensplate and a rear extension unit. This combination allows for optimised shift without vignetting from the lensbarrel.This lenspanel features an integrated tilt and swing mechanism which can be operated with two precise gear-driven knobs upto 5 degrees Tilt up and down and 5 degrees Swing left and right, while both swing and tilt can be set independently, separately but also in combination. The movements have a clear and forced zero position where the parallel setting to the focal plane is guaranteed. The WTSA-890 fits to all Cambo Wide cameras with SLW-adapters.Optical MovementsCCD size 37x37mm: 33/33mmCCD size 33x44mm: 29/26mmCCD size 36x48mm: 26/23mmCCD size 37x49mm: 25/22mmCCD size 40x54mm: 23/21mmCCD size 36x56mm: 25/21mmCamera MovementsWDS: Up / Down / Left / Right: 34 / 26 / 20 / 20mmWRS: Up / Down / Left / Right: 25 / 15 / 20 / 20mm
