Cambo WDS-549 Lens Panel with Rodenstock HR Digaron-W 32mm f/4 Lens, Copal #0

The WDS-549 Lenspanel is dedicated to the use with Digital Backs and has a Rodenstock 4,0/32 HR Digaron-W lens with copal0 shutter mounted in a helical focussing mount.Shortest focal distance to object: 0.3 meterImage circle of lens at f/8: 90mmOptical Movements:CCD size 37x37mm: 23/23mmCCD size 33x44mm: 23/20mmCCD size 36x48mm: 20/17mmCCD size 37x49mm: 19/17mmCCD size 40x54mm: 15/13mmCCD size 36x56mm: 17/13mmCamera Movements:WDS: Up / Down / Left / Right: 34 / 26 / 20 / 20mmWRS: Up / Down / Left / Right: 25 / 15 / 20 / 20mmHR Digaron-W Features• Resolution up to 100 line pairs/mm, pixel size up to 5 micrometer• The open aperture is free of vignetting and can be used as a working aperture• Excellent imaging performance at working apertures from 5.6 to 8• To avoid blurring and color fringing caused by the sensor protection glass, the calculation of the optical design includes a 2 mm thick sensor glass• Perfect symmetric reproduction due to a special adjustment of the optical elements• Thanks to the retro focus design of the wide-angle lenses there is no additional light fall-off and no color fringing on the sensors with micro lenses due to extremely oblique light incidence• Enough space left for camera movement between lens and sensor even with short focal lengths.
