Caddx Turtle FOV 145 Degree Super WDR Mini FPV Camera 1080P 60fps DVR HD Recording OSD for RC Drone

Specification Image sensor: 1/2.7" CMOS sensor Horizontal: 800TVL TV system: NTSC/PAL,changeable Video Resolution: 1080P@60fps / 720@60fps Power Input: DC 4.5-20V FPV FOV : 155 Recording FOV :170 Mini Illumination: 0.1lux Image Resolution: 2 Megapixels Lens: Full Size Turbo Eye Lens Working Current: 380mA@5V/160mA@12V (low consumption) OSD Menu: Yes (Support Voltage Display) Video Files: MOV ELectronic shutter : PAL : 1/50-100,000 NTSC : 1/60-100,100 S/N Ratio: >60dB (AGC OFF) Video Output: CVBS Max Micro SD Card Supported: 8-64GB(need Class 10 or above,recommend Class 10/UHS-I/UHS-II) Dimension: SD Slot Module 28*29mm / Camera 19*19mm (installed with 20*20mm, expand to 30*30mm ) Working Temperature: -20~+60 Net weight: 12g(more or less) Package Included 1 x Caddx Turtles Camera 1 x 5D-OSD Menu Board 1 x Bracket for camera 2 x Extended bracket for 1080P HD recorder 1 x 4pin FPV Silicon Cable (extend into a 2pin joint for OSD board and a 3pin joint for FPV) 3 set x Screw 1 set x Copper cylinders 1 x Internal hexagonal wrench 1 x Manual 1 x Warranty card All order from 2nd August will send extra 2 Pairs Gemfan Flash 5149 Propeller as gift Quick operation guide 1. RIGHT BUTTON Press the RIGHT button for 3s-5s to activate video recording, in the meanwhile the light on the lower right corner will flicker. 2. LEFT BUTTON Press the LEFT button for 3s-5s to stop video recording. 3. DOWN BUTTON Press the DOWN button for 3s-5s to switch the resolution, 720P with Blue LED on, 1080P with Red LED on, the default mode is 1080P. 4. MIDDLE BUTTON The MIDDLE button is menu button. Notice: The camera need at least 8G Class 10 SD card. Notes:If the power is cut accidentally when video recording,please power on again, then the camera will automatically restore the memory, and the video records before power cut will be still saved in TF card.
