Cable unipolar maquina soldar sec. 70,00 mmq rojo

Código ErreBi: 30606 Venta por metros Cables for welding machines material: PVC tipology: SINGLECORE Applications: Welding Cables Conditions of employment For secondary side connection of powers sources for hand or automatic metal-arc welding for secondary voltage typical of welding equipment. Type of electrical conductor: Flexible red copper Main rule: - Self-extinguishing: EN 60332-1-2 , IEC 60332-1-2 Description PVC insulated cables for welding machines. Review number:n. 4 - 23/2/2011 Nominal tension: 450/750 V Type of outer sheath: TM2 Color of the outer sheath: Black Operating temperature: +5° C | +70° C Short circuit temperature: 160° C °C Test voltage: 2500 V Cable marking: ELFLEX (sect) mm² CE Minimum radius of curvature: For cables with diameter up to 12 mm: 5 times the max. outer diameter in case of non-constrained motion and 4 times in case of fixed installation. For cables with greater diameter: 6 times the max. outer diameter in case of non-constrained motion and 5 times
