Cable Unipolar UL Style 1213 AWG 24 Teflon PTFE 600V Azul

Código ErreBi: 25647 Código productor: 5854/7 BL Productor: Alpha Wire Venta por metros The PTFE wire with high temperature resistance, chemical and solvent resistance and excellent electrical properties. This 600V PTFE wire can be used at temperatures ranging from -60°C to + 200°C depending on the application. Silver-plated braided copper conductors that protect wires from corrosion and increase efficiency in hot and humid environments. Easy to handle, strip and finish. PTFE insulation. The connecting wire can be used for a wide range of applications, be it in a control cabinet, high temperature furnace or specialized machine tool. Conductor section: 0.23 mm2 Sheath color: Blue AWG: 24 AWG Conductor strands: 7 / 0.20 mm Insulation material: PTFE Outer diameter: 1.12mm Rated voltage: 600V Conductor material: Silver-plated copper Wire type: UL1213 Operating temperature: -60°C to + 200°C Shield type: Unshielded Standard: MIL-W-16878/4, NEMA HP-EXBBB, UL1213, VW-1 Insulation thickness:
