Ca-35Rs Pl259 So239 Radio Connector Adapter Repeater Coaxial Antenna Surge Protector Lightning Arrestor

Feature The Surge Protector is a lightning amestor of coaxial construction The device is designed to absorb the surge of lightning strikes on an antenna at the top of a bulking and ground it thus providing full lightning protection for transceivers receivers etc1 Designed with a stress on high safety this device has a built in gas charging surge arrestor element which discharges and ground the surge at the moment the surge voltage exceeds a specified level 2This device makes the actions of surge discharge and restoration as repeatedly as necessary No replacement is practically needed 3 Should the surge arrestor element be damaged it can easily be replaced with a new element4 The coaxial construction of this device assures excellent high frequency characteristics wide bandwidth and low loss and VSWR Operation 1 When using the Coaxial Lightning Surge Protector under the eaves connect it with an antenna cable For connection mount a plug male connector on both ends of antenna cable 2 Clinch or solder a copper wire 2 5 to 3 2mm diameters and connect top end of the wire to lightning escape ground buried deep in the soil ground It is recommended to connect the item and the ground as short as possible3 Be sure to ground lighting protector firmly It is recommended to refer to a book on grounding or consult with a specialist in the field A Use isolated independent ground Do not share the ground with power line safety ground which is used to avoid electrocution B Make ground
