CYS-S8221 9g Digital Metal Gear Servo for RC Models

CYS-S8221 Digital Metal Gear Servo for RC Models Description: Item No. CYS-S8221 Type Digital Weight 1 3g Size 22.9*12*25.4mm Control System (+)Pulse Width Control 1500usec Neutral Required Pulse Operating Voltage 4.8~6.0Volts Operating Temperature Range (-)10 to +50 degree C Operating Speed (4.8V) 0.10sec/60 at no load Operating Speed (6.0V) 0.08sec/60 at no load Stall Torque (4.8V) 1.0kg.cm Stall Torque (6.0V) 1.2kg.cm Operating Angle 45deg.one side pulse traveling 500 usec 360 Modifiable No Direction Anticlockwise/Pulse Traveling 1000~2000usec Current Drain (4.8V) 10mA/idle and120mA no load operating Current Drain (5.0V) 10mA/idle and 140mA no load operating Stall Current 900mA/1000mA Dead Band Width 2usec Motor Type 3 Pole Ferrite Drive Bearing Type Dual Ball Bearing Horn gear spline 21T Gear Type Metal Important Notes: -Refer to the figure when installing the servo accessories. -For engine powered airplanes and boats, rubber must be used to reduce vibration. - Please choose correct model for your application. -Torque over-loaded will damage the servo's mechanism-. - Keep the servo clean and away from dust, corrosive gas and humid air. Package Included: 1 xCYS-S8221 Digital Metal Gear Servo
