CYS-S8218 40KG Metal Gear Digital 6V-7.4V High Torque HV Servo for 1/5 RC Car

CYS-S8218 40KG Metal Gear Digital 6V-7.4V 0.18s-0.20s/60 High Torque HV Servo for 1/5 RC Car The CYS-S8218 is a well designed and high quality servo which is digital, fitted with metal gears for reliability. It is made of high quality material, which may make your operation much more remarkable. Features: Easy to install Made of aluminum alloy material Stall torgue of 36kg.cm(6.0V) 38kg.cm (7.4V) High precision metal gear Suit for 1/5 RC car Specification: Item No. CYS-S8218 Type Digital Weight 164g Size 59.5*29*55.2mm Control System (+)Pulse Width Control 1500usec Neutral Required Pulse Operating Voltage 6.0~7.4Volts Operating Temperature Range (-)10 to +50 degree C Operating Speed (6.0V) 0.20sec/60 at no load Operating Speed (7.4V) 0.18sec/60 at no load Stall Torque (6.0V) 36kg.cm Stall Torque (7.4V) 38kg.cm Operating Angle 45deg.one side pulse traveling 500 usec 360 Modifiable No Direction Anticlockwise/Pulse Traveling 1000~2000usec Current Drain (6.0V) 20mA/idle and 700mA no load operating Current Drain (7.4V) 20mA/idle and 900mA no load operating Stall Current 7.5A/8.6A Dead Band Width 4usec Motor Type 3 Pole Ferrite Drive Bearing Type Dual Ball Bearing Horn gear spline 17T Gear Type Meta Important Notes: -Refer to the figure when installing the servo accessories. -For engine powered airplanes and boats, rubber must be used to reduce vibration. - Please choose correct model for your application. -Torque over-loaded will damage the servo's mechanism-. - Keep the servo clean and away from dust, corrosive gas and humid air. Package Included: 1 *CYS-S8218 40KG Digital Servo 1 * Spare Parts Set
