CS1-G Magnetic Air Pneumatic Cylinder Magnetic Reed Switch Sensor DC AC 5V- 240V
![CS1-G Magnetic Air Pneumatic Cylinder Magnetic Reed Switch Sensor DC AC 5V- 240V](http://i5.walmartimages.com/asr/7e036abc-3e1c-4da6-a0d1-a18a6d87c726.373469436efa87bc5144841c68438484.jpeg?odnHeight=450&odnWidth=450&odnBg=ffffff)
ABIDE
sku: 1157093238
ACCORDING TO OUR RECORDS THIS PRODUCT IS NOT AVAILABLE NOW
$6.84
Shipping from: United States
Description
Features: 100% brand new and high quality Used for Pneumatic Cylinder SDA/ QCK This Magnetic Sensor Switchhas strong overload capacity High sensitivity and stable performance Magnetic Sensor Reed Switchis easy to wire and use Specification: Model:CS1-G Installation: rail installation Switch selection: SPST normally open type Induction switch type: with node reed type Operating voltage: 5-240v DC/AC MAX switching current: 100mA MAX capacity: 10W Internal consumption current: none Residual pressure drop: 2.5v MAX Leakage current: no Indicator light: red LED MAX switching frequency: 200Hz Impact resistance: 30G Protection back: none Weight: Approx.18g/0.6oz Package list: 1 x Magnetic Sensor Reed Switch
