CRL RS0B20PS 316 Polished Stainless Steel Standard 2 Glass Rail Standoff Fitting with Mounting Plate

Our CRL Glass Rail Standoff Fittings can be used to mount glass up to 27/32 (21.52 mm) thick. This Alloy 316 stainless steel assembly can be mounted to a wood concrete or steel substrate and features 2 (51 mm) diameter caps on threaded bolts to secure the glass. The 2 (51 mm) diameter Standoffs are fastened to a 3/8 (10 mm) thick stainless steel plate that is pre-drilled for mounting. Two popular stainless finishes are available from stock. SPECIFICATIONS: For use with 1/2 to 27/32 (12 to 21.52 mm) Tempered Monolithic or Tempered Laminated Glass (Do Not Use with Raw or Annealed Glass) Glass Fabrication: Two 3/4 (19 mm) Diameter Holes Per Fitting Spacing: Maximum spacing between fittings depends on use and mounting conditions; Hole spacing between Standoffs is 4 (102 mm). Important Notes: For use with 1/2 – 27/32 (12 – 21.52 mm) tempered monolithic or tempered laminated glass. Do not use with raw or annealed glass) NOTE: Bracket spacing and maximum glass panel widths vary depending on use and mounting conditions.
