CRL D2301A48 Satin Anodized 48 Deluxe Packaged Track Assembly D603 Upper and D601 Rail with Nylon Wheels

The CRL Deluxe Track Assembly is smooth working reliable and attractive. It is available in three pre-cut easy-to-install lengths. These 36 48 and 72 (914 mm 1.22 m and 1.83 m) assemblies are the perfect solution for your custom project. Cut-to-length extrusions save you installation time and minimize material loss. The H Bar is cut to permit a 1-1/2 (38 mm) overlap. The combination Lower Channel matches the design of the Upper Channel. CRL Cat. No. D332 End Caps for H Bar Extrusion can be purchased separately. For dry glazing with 1/4 (6 mm) glass use Cat. No. GC728C Vinyl (sold separately). CRL also has a large selection of Locks available to secure the sliding doors. CRL Ratchet and Plunger Type Locks are available. NOTE: Maximum suggested panel size is 36 W x 48 H (914 mm x 1.22 m). General Glass Cutting Guidelines: Glass Height = Opening Height Minus 1-3/8 (35 mm). Important Notes: If you need a very tight fit you should figure your own dimensions. The dimensions shown are just guideline dimensions that are satisfactory to most installers. D2203 Series = Rolling Track Assembly: Glass Height = Opening Minus 1-1/8 D2204 Series = Rolling Track Assembly: Glass Height = Opening Minus 1-1/8 D2300 Series = Rolling Track Assembly: Glass Height = Opening Minus 1-3/8 D2301 Series = Rolling Track Assembly: Glass Height = Opening Minus 1-3/8 D2303 Series = Rolling Track Assembly: Glass Height = Opening Minus 1-3/8 D2305 Series = Rolling Track Assembly: Glass Height = Opening Minus 1-3/8 D2306 Series = Rolling Track Assembly: Glass Height = Opening Minus 1-5/8 D2307 Series = Rolling Track Assembly: Glass Height = Opening Minus 1-5/8
