CM410X 2.4G 4CH DSM2 DSMX Compatible Receiver With PPM Output For Radio Transmitter

CM410X 2 4G 4CH DSM2 DSMX Compatible Receiver With PPM OutputDescription Item Name CM410X receiverBand 2 4GHzChannel 4CHModulation DSM2 DSMXDimensions L xWx H 29x15x4mmWeight 2gVoltage Range 3 3 15VBrown Out Voltage 4 0v Always supply power above this voltage Antenna Length Main RX 13 5cm 2 Expected Range 800m tested with JR DSX9 Key Features 4channelswith PPM OutPatent pending Model Match prevents flying a model using the wrong model memory feature does not work with module systems ServoSync feature does not work with module systems Preset failsafe systemQuickConnectCompatibility Spectrum and JR DSM2 DSMX DX6I DX7 DX8 DSX7 DSX9DSX11BindingProcedure I Pressbind buttonconnectpower to receiver please make sure radio in binding process Receiver LEDquick flash then green LED keep lightit means bind is accomplished II Please make sure the transmitter in binding process III To set fail safe throttle and control surface positions minimum throttle and all control surfaces set to neutral is suggested Press and hold the bind button of transmitter LED will illuminate Turn on the transmitter III Receiver LED will change from rapid flashing to slow flashing and a few seconds later when bind is accomplished the LED of receiver will illuminate solid Failsafeshould be programmed correctly IV Remove binding harness from the BIND channel Restart the receiver by cycling it power off and turn onand connect battery into BIND channel is recommended All channels should
