CM275T 5.8G 25mW 48CH NTSC/PAL Mini VTX 600TVL FPV Camera for DIY Micro FPV Racer

CM275T 5.8G 25mW 48CH NTSC/PAL Mini VTX 600TVL FPV Camera for DIY Micro FPV Racer Description: Item name:CM275T 5.8G 25mW 48CH NTSC/PAL Mini VTX 600TVL FPV Camera Suitable for: DIY Micro FPV Racer Weight:3.35g Electrical Characteristics: Frequency band:5362-5945 MHz Channel customer:48 Modulation:FM Channel SEL.:Touch Switch Channel Indicate:CHI-CH8 Channel indication with 8LEDS and A~F frequency group Indicate with 6LEDS Transmit power:13 1dBm Frequency control:PLL All harmonic:Max-50dBm Frequency Stability: 100KHz(Typ.) Frequency precision: 200KHz(Typ.) Channel Carrier error:1dB Antenna Port:50 Input format:NTSC/PAL SENSOR:PAL:720X540/NTSC:640X480 1/4" LENS ANGEL:H:120/V:100 Base -band interface:P1.27*2 Power consumption:200~215MA@5V DCIN Supply Voltage:2.9-5.5v Operating Temperature:-10~+60 Profile dimension:14.5mmX12.2mm+14.5mmX12mm Features: 1.This product CM275T is a 5.8G wireless camera 2.48 Channel 3.Support touch switch select channel Frequency group 4.Support NTSC/PAL switch Support vertical inverted image switch 5.8LED display channel and 6LEDS display frequency group information;1LED display PAL/NTSC and FLIP information 6.Wide lens angle 7.Miniature and light weight design Package Included: 1 x 5.8G 48CH FPV Camera (without Stickers and Rubber band) 2 x Camera protection cover (red & black)
